MLA System USER GUIDE
MLA System User Guide V2.1 76
NOMINAL POWER CONSUMPTION 600W
MAINS CONNECTOR 16A IEC309 (Ceeform) – IP44 rated
General
ENCLOSURE Vertical trapezoid with 5⁰ wall angle, multi-laminate birch and poplar-ply
construction
FINISH Textured black PU coating
PROTECTIVE GRILLE Black HEX perforated steel
FITTINGS Proprietary rigging system
Bar handles on each side
Protective Rubber side-cheeks incorporating skids
Weather Protection Cowl
IP RATING IP 25
DIMENSIONS (W) 788mm x (H) 280mm x (D) 500mm
(W) 31in x (H) 11in x (D) 19.7in
WEIGHT (ex. wheelboard) 49.5kg (109lbs)
Accessories
Flightcase for two enclosures
Flying frame (including clinometer)
Ground stacking bar
Flying Pin
Mains distribution system
Tour-grade network interconnects
Merlin Controller/U-Net Hub
Notes
(1) Measured on-axis in open (4) space at 4 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in half-space at 1 metre with a tone burst signal, then referred back to open (4) space.
(4) Calculated from 4m 2.83v sensitivity, referred to 1m.
