MLA System USER GUIDE
MLA System User Guide V2.1 35
1 x low-speed internal blower
1 x temperature controlled external fan
MAXIMUM AMBIENT TEMPERATURE 45°C (113°F) for full output
Power Supply
TYPE Switch mode, fixed frequency with PFC
AC INPUT OPERATING RANGE 100 – 240V ~ AC, 50 - 60Hz
AC OVERVOLTAGE TOLERANCE 400V AC
POWER FACTOR > 0.95
NOMINAL POWER CONSUMPTION 900W
MAINS CONNECTOR 16A IEC309 (Ceeform) – IP44 rated
General
ENCLOSURE Vertical trapezoid with 3.75⁰ wall angle, multi-laminate birch and poplar ply
construction
FINISH Textured black PU coating
PROTECTIVE GRILLE Black HEX perforated steel
FITTINGS Proprietary rigging system
Bar handles on each side
Protective Rubber side-cheeks incorporating skids
Wheel-board
Transit cover
Weather Protection Cowl
IP RATING IP 24
DIMENSIONS (inc. wheelboard) (W) 1136mm x (H) 372mm (376mm) x (D) 675mm (825mm)
(W) 44.7in x (H) 14.6in (14.8in) x (D) 26.5in (32.4in)
WEIGHT (ex. wheelboard) 87.5kg (193lbs)
Accessories
Flying frame (including clinometer)
Ground stacking bar
Flying Pin
Mains distribution system
Tour-grade network interconnects
Merlin Controller/Unet Hub
Notes
(1) Measured on-axis in open (4) space at 4 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in half-space at 1 metre with a tone burst signal, then referred back to open (4) space.
(4) Calculated from 4m 2.83v sensitivity, referred to 1m.
