13.4 Acquisition Control 111
TriggerOverlap[TriggerSelector] triggerOverlap Specifies the type trigger overlap
permitted with the previous frame.
TriggerOverlap is only intented for
external trigger (which is usually
non-overlapped: i.e. exposure and
readout are sequentially). This
leads to minimal latency / jitter be-
tween trigger and exposure.
However, the camera accepts a
new trigger (the exposure time ear-
lier) before the end of the transmis-
sion of the current image.
Maximum frame rate in triggered
mode = frame rate of continuous
mode
This however leads to higher la-
tency / jitter between trigger and
exposure.
A trigger will be not latched if it oc-
curs before this moment (trigger is
accurate in time).
See also
Principles of overlapped
and pipelined trigger
(p. 158).
ExposureMode exposureMode Sets the operation mode of the Ex-
posure (or shutter).
ExposureTime exposureTime Sets the Exposure time (in mi-
croseconds) when ExposureMode
is Timed and ExposureAuto is Off.
ExposureAuto exposureAuto Sets the automatic exposure mode
when ExposureMode is Timed.
etc.
related to the image acquisition, including the triggering mode.
Additionally, MATRIX VISION offers numerous additional features like:
• mvShutterMode
which selects the shutter mode of the CMOS sensors like rolling shutter or global shutter.
• mvDefectivePixelEnable
which activates the sensor's defective pixel correction.
See also
https://www.matrix-vision.com/tl_files/mv11/Glossary/art_image_←-
errors_sensors_en.pdf
• mvExposureAutoSpeed
which determines the increment or decrement size of exposure value from frame to frame.
• mvExposureAutoDelayImages
the number of frames that the AEC must skip before updating the exposure register.
MATRIX VISION GmbH
