126 CONTENTS
SequencerTriggerActivation sequencerTriggerActivation Specifies the activation mode of
the sequencer trigger. Possible
values are:
• RisingEdge: Specifies that
the trigger is considered
valid on the rising edge of
the source signal.
• FallingEdge: Specifies that
the trigger is considered
valid on the falling edge of
the source signal.
• AnyEdge: Specifies that the
trigger is considered valid on
the falling or rising edge of
the source signal.
• LevelHigh: Specifies that the
trigger is considered valid
as long as the level of the
source signal is high.
• LevelLow: Specifies that the
trigger is considered valid
as long as the level of the
source signal is low.
The sequencer mode can be used to set a series of feature sets for image acquisition. The sets can consecutively
be activated during the acquisition by the camera. The sequence is configured by a list of parameters sets.
Note
At the moment, the Sequencer Mode is only available for MATRIX VISION cameras with CCD sensors and
Sony's CMOS sensors.
The following features are currently available for using them inside the sequencer control:
• BinningHorizontal
• BinningVertical
• CounterDuration (can be used to configure a certain set of sequencer parameters to be applied for the next
CounterDuration frames)
• DecimationHorizontal
• DecimationVertical
• ExposureTime
• Gain
