20.2 Introducing acquisition / recording possibilities 183
20.2.6.1 Triggered frame burst mode
With the triggerSelector "FrameBurstStart", you can also start a frame burst acquisition by a trigger. A defined
number of images ("AcquisitionBurstFrameCount") will be acquired directly one after the other. With the "mv
Acquisition Frame Rate Limit Mode" set to mvDeviceMaxSensorThroughput , the there won't be hardly any
gap between these images.
As shown in figure 5, "FrameBurstStart" can be trigger by a software trigger, too.
Figure 5: wxPropView - Setting the frame burst mode triggered by software
MATRIX VISION GmbH
