MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
18. BPLL_CFG0: BB PLL Configuration 0 (offset: 0x0048)
BB PLL Software Configuration
Sets BB PLL parameters set by software.
0: Apply default parameters set by hardware.
1: Apply new parameters set by software in
BPLL_CFG0 & BPLL_CFG1.
BB PLL Power Down
0: Power On
1: Power Down
BB PLL Feedback Divisor 2
This value depends on the bootstrap pin.
<0x0>: 40 MHz
<0x1>: 20 MHz
BB PLL Frequency Output Divisor 2
0: Fixed at 960 MHz
BB PLL Reference Input Divisor
divisor: M=RDV[3:0])
BB PLL Feedback Divisor Control
Sets the real feedback divisor (N) based on the
value of BBPL_FBDV2 (bit13).
If FBDV2=0, N=FDV[3:0]+16
If FBDV2=1, N=2*(FDV[3:0]+16)
FOUT Frequency Control
Sets the real output divisor (P) based on the
value of BBPL_FOUTDIV2 (bit12).
If FOUTDV2=0, P=ODV[3:0]
If FOUTDV2=1, P=ODV[3:0]*2
NOTE: In this chip ODV[3:0]=0000, so FOUT=0.
19. BPLL_CFG1: BB PLL Configuration 0 (offset: 0x004C)
Lock-detector state
0: Not locked
1: Locked
