VM600 MPS hardware manual (standard version) MAMPS-HW/E 9 - 7
Edition 17 - February 2018
Connecting vibration and pressure sensors
CONFIGURATION OF MPC4 / IOC4T CARDS
LS12x + ILS73x
Voltage output:
0to10V
18 to 30 V
DC
External supply Figure 9-11
Current output:
4to20mA
170 mA
(600 mA start-up
current)
External supply Figure 9-12
Displacement transducers
AE119
4to12mA for
50 mm.
4 to 20 mA full
scale.
+20 to +30 V
DC
max. 60 mA
External supply Figure 9-12
Pressure sensors
CP1xx + IPC704 12 mA ±5 mA
+18 V
DC
±10%,
I
max
17 mA
External supply Figure 9-5
Table 9-2: Use of an internal (MPC4) or external power supply for various types of sensors (continued)
Transducer or
transducer and
signal conditioner
Output signal Rating Supplied by
Connection
diagram
