Page 105
Appendix| Factory Setting
optoNCDT 1700
A 2 Factory Setting
Name Setting
LED Level 1 Level 2 Level 3
output Current Hold last value Sync/Error
speed 2.5 kHz Master Synch off 115.2 KBaud
avg 1 (3) Moving average Binary format (no ASCII)
zero off ... ...
Master value: 0.5 x measurement range
Upper limit: 101 % FSO / Digital value: 16365
Upper hysteresis value: 100 % FSO / Digital value: 16207
Lower hysteresis value: 0 % FSO / Digital value: 161
Lower limit: -1 % FSO / Digital value: 0
Press the „function/enter“ key 5 seconds to activate the factory settings if the sensor is in measurement mode
(the “state“ LED is illuminated).
