Measurement Value Output
optoNCDT 1700
Digital value Conversion Measurement value
8184 (8184 * 6.23167e-5 - 0.01) * 10 mm = 5 mm (=MMR)
10261 (10261 * 6.23167e-5 - 0.01) * 10 mm = 6.294 mm
161 (161 * 6.23167e-5 - 0.01) * 10 mm = 0 mm (=SMR)
Note: A digital value can be calculated from a measurement value (millimeter) as follows:
digital = + 0.01 *
OUT
x [mm]
MR [mm]
16368
1.02
This formula can be used, for example, in the program-
ming of switching thresholds, see Chap. 8.5.7.
7.4 Digital Error Modes
Digital error codes are issued in the same way
as measurement values.
Value range for error codes:
16370 ... 16383 (digital OUT)
F1 bad object
F2 out of range -
F3 out of range +
F4 poor target
F5 Laser off
16370 No object detected
16372 Too close to sensor
16374 Too far from sensor
16376 Object cannot be evaluated
16378 external laser off
16380 Sensor in trigger mode
Trigger pulses come to fast.
