MICRO-EPSILON ILD1700-2 - Error Output (Analog Output)

Page 82
Serial Interface RS422
optoNCDT 1700
8.5.12 Error Output (Analog Output)
Name: SET_ERRORHANDLER
Description: Switches on the flag for keep / do not keep the last measurement value
This flag only affects the analog output. If set to X = 1 the last valid measurement value will continue to be is-
sued if an error occurs (no object, invalid object, object outside the measurement range or laser turned off). If
set to X = 0 an error signal will be generated for the current output that has an error value of 3 mA and for the
voltage output that has a value of 10.2 V.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x81 0x00 0x03 0x20810003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x81 0x00 0x02 0xA0810002
0x20 0x20 0x0D 0x0A 0x20200D0A
Options:
X = 0 > Do not hold
the last value
X = 1 > Hold last
value
