Serial Interface RS422
optoNCDT 1700
8.5.19 Reading out the Measurements
Name: GET_MEASVALUE
Description: The command is used for polling measurements in trigger mode. The amount of mea-
surements which the sensor should supply must be specified in the parameter. The command DAT_OUT_
OFF resets the amount of possible measurements to be transferred to 0.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x2C 0x00 0x03 0x202C0003
0xXX 0xXX 0xXX 0xXX 0xXXXXXXXX
Measurements are output in binary, see Chap. 8.2.1 or ASCII format, see Chap. 8.2.2, in trigger mode.
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xE0 0x2C 0x00 0x03 0xE02C0003
0x00 0x00 0x00 0x05 0x00000005
0x20 0x20 0x0D 0x0A 0x20200D0A
