Measurement Value Output
optoNCDT 1700
7.2 Current Output
Max. range 4 mA ... 20 mA
Output amplification  I
OUT
16 mA = 100 % Measuring range
Error value: 3 mA (±3 μA)
Calculation of measurement value x in mm from analog current
Reference value SMR: Reference value MMR:
x [mm] = (I
OUT
- 4 mA)*
MR [mm]
16 [mA]
x [mm] = (I
OUT
- 4 mA)* - MR/2
MR [mm]
16 [mA]
Example: Measuring range = 10 mm, I
OUT
= 12 mA; Result: x = 5 mm respectively x = 0 mm
7.3 Digital Value Output
The digital measurement values are issued as unsigned digital values (raw values).
Digital value Used for Digital value Used for
0 ... 16367 Value range 16208 ... 16367 EMR back-up (1 %)
0 ... 160 SMR back-up (1 %) 16370 ... 16383 Error codes
161 ... 16207 Measurement range
Calculation of a measurement value in mm from digital output
Reference value SMR: Reference value MMR:
x [mm] = (digital
OUT
* - 0.01) * MR [mm]
1.02
16368
x [mm] = (digital
OUT
* - 0.51) * MR [mm]
1.02
16368
Example: MR =10 mm, Reference value = SMR
