Serial Interface RS422
optoNCDT 1700
8.5.10 Set the Measurement Value Output Type
Name: SET_OUTPUTTYP
Description: Sets the output type for the measurement values.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x90 0x00 0x03 0x20900003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x90 0x00 0x02 0xA0900002
0x20 0x20 0x0D 0x0A 0x20200D0A
8.5.11 Set Measurement Frequency (Speed)
Name: SET_SPEED
Description: Sets the measurement frequency
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x85 0x00 0x03 0x20850003
0x00 0x00 0x00 0x0X 0x0000000X
Options:
X = 0 > 2.5 kHz
X = 1 > 1.25 kHz
X = 2 > 625 Hz
X = 3 > 312.5 Hz
Options:
X = 0 > Current
(4..20 mA)
X = 1 > Voltage
(0..10 V)
X = 2 > RS422
