Serial Interface RS422
optoNCDT 1700
8.5.2 Reading out the Sensor Parameters
Name: Get_Info
Description: Supplies the info string. This shows all parameters currently stored in the sensor.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x49 0x00 0x02 0x20490002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x49 0x00 0x70 0xA0490070
Info string in the form of a readable ASCII character string:
ILD 1700 : Standard
output : RS422err
frequency : 2500 Hz
average-number : 1
syncmode
1
: M S off
keylock: no
range: 10
option : 0
date: 06/03/09
sw type: 0
Softwareversion : 5.005
speed : 1
average-type : moving
hold value : yes
ASCII-output: no
Flash enable: yes
serialnumber: 1234568
articlenumber : 4120088
bootloaderversion: 1.52
0x20 0x20 0x0D 0x0A 0x20200D0A
1) Depends on operation mode settings (synchronization or trigger). Options with synchronization: Master
sync. off, master sync. on, slave, master alternating. Options with trigger: Edge LH, edge HL, level H, level L
IMPORTANT!
If initialization has been
finished, the sensor
transmits the info
string once in ASCII
format. The initialization
including the info string
transmission takes up
to 10 seconds. Within
this period, the sensor
neither executes nor
replies commands.
