Page 76
Serial Interface RS422
optoNCDT 1700
8.5.6 Starting and Stopping the Measurement Value Output
Name: DAT_OUT_ON
Description: Switches on the digital data output for the measurement values. The output channel
(output type) must also be set to the digital output, otherwise the measurement data cannot be received by
the sensor.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x77 0x00 0x02 0x20770002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x77 0x00 0x02 0xA0770002
0x20 0x20 0x0D 0x0A 0x20200D0A
Name: DAT_OUT_OFF
Description: Switches off the digital output for the measurement values. This has no effect on
communication with the sensor via the digital interface. This command has a higher priority than
GET_MEASVALUE in trigger mode.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x76 0x00 0x02 0x20760002
Advice: The sensor sends digital measurement values again when the operating voltage has been switched
on again.
Start command
Stop command
IMPORTANT!
The STOP command
is volatile and is lost
if the power supply is
switched off or the
RESET_BOOT
command is sent.
