MICRO-EPSILON ILD1700-2 - Switching off the Laser (External)

Page 84
Serial Interface RS422
optoNCDT 1700
8.5.14 Switching off the Laser (External)
Name: LASER_OFF
Description: Switches off the laser.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x86 0x00 0x02 0x20860002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x86 0x00 0x02 0xA0860002
0x20 0x20 0x0D 0x0A 0x20200D0A
Name: LASER_ON
Description: Switches the laser on
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x87 0x00 0x02 0x20870002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x87 0x00 0x02 0xA0870002
0x20 0x20 0x0D 0x0A 0x20200D0A
The command LASER_ON is effective only if pin 9 is connected with GND.
IMPORTANT!
The command
LASER_OFF is
volatile. This means
that the laser is
switched on again if
the power supply
was switched off or
the sensor was
rebooted by means
of the RESET_BOOT
command and pin 9
is connected with
GND.
