Serial Interface RS422
optoNCDT 1700
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF1 0x00 0x02 0x20F10002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF1 0x00 0x02 0xA0F10002
0x20 0x20 0x0D 0x0A 0x20200D0A
8.5.18 Reset Sensor
Name: RESET_BOOT
Description: Starts the sensor’s initialization phase. The set parameters are retained. The short-circuit
protection for the switch outputs is also reset in the process.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0xF0 0x00 0x02 0x20F00002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0xF0 0x00 0x02 0xA0F00002
0x20 0x20 0x0D 0x0A 0x20200D0A
IMPORTANT!
The volatile com-
mands Laser_off and
DAT_ UT_ OFF are lost
after the RESET com-
mand.
This means that the
laser is switched on
again and the sensor
sends measurement
values again.
