Serial Interface RS422
optoNCDT 1700
8.5.15 Switching the Data Format
Name: ASCII_OUTPUT
Description: Switches the data format for the measurement value output via the digital interface.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x88 0x00 0x03 0x20880003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x88 0x00 0x02 0xA0880002
0x20 0x20 0x0D 0x0A 0x20200D0A
Options:
X = 0 > Binary output (2 Byte)
X = 1 > ASCII output (6 Byte)
