Page 86
Serial Interface RS422
optoNCDT 1700
8.5.16 Key Lock
Name: SET_KEYLOCK
Description: Locks or enables the membrane keys. The set status is not volatile.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x60 0x00 0x03 0x20600003
0x00 0x00 0x00 0x0X 0x0000000X
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x60 0x00 0x02 0xA0600002
0x20 0x20 0x0D 0x0A 0x20200D0A
8.5.17 Set Factory Setting
Name: SET_DEFAULT
Description: Resets the set parameters to the default settings (factory settings).
This concerns:
- Output type (current)
- Measurement frequency
- Averaging number (1)
- Hold last measurement value,
- Synchronization (no synchronization),
- Averaging type (moving),
- Operation mode (sync error),
- Baud rate (115200 baud),
- Binary output,
- Laser (on),
- Data output (on),
Options:
X = 0 > Enable keys
X = 1 > Lock keys
- Assignment of the switching outputs (upper limit > F1, lower
limit > F2),
- Default values for master, offset, limit and hysteresis values
- Keys enabled
- Flash enabled
