MICRO-EPSILON ILD1700-2 - Set Limit Values

Page 77
Serial Interface RS422
optoNCDT 1700
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x76 0x00 0x02 0xA0760002
0x20 0x20 0x0D 0x0A 0x20200D0A
8.5.7 Set Limit Values
Name: SET_LIMITS
Description: Sets limits and hysteresis values in the operation mode „Sync. switch mode“ respectively
„Trigger switch mode“ (upper/lower limit, upper/lower hysteresis value).
31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x7E 0x00 0x07 0x207E0007
Upper limit value
0x00 0x00 0xXX 0xXX
0x0000XXXX
Lower limit value
0x00 0x00 0xXX 0xXX 0x0000XXXX
Upper hysteresis value
0x00 0x00 0xXX 0xXX 0x0000XXXX
Lower hysteresis value
0x00 0x00 0xXX 0xXX 0x0000XXXX
Master value
0x00 0x00 0xXX 0xXX 0x0000XXXX
Note: The hysteresis
values have the effect
of resetting the as-
signed switch outputs
when the measurement
values return to the
target range.
