Page 78
Serial Interface RS422
optoNCDT 1700
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x7E 0x00 0x02 0xA07E0002
0x20 0x20 0x0D 0x0A 0x20200D0A
Note: All values are absolute values; Input as an integer value (whole number count value) of 2 bytes, com-
pleted by two advance bytes with the value “0“ to a total length of 32 bits.
8.5.8 Assignment of the Limits to the Switch Outputs
Name: SET_UPPERLIMIT_F1
Description: Assigns the upper limit to switching output 1 and the lower limit to switching output 2.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x83 0x00 0x02 0x20830002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x83 0x00 0x02 0xA0830002
0x20 0x20 0x0D 0x0A 0x20200D0A
Name: SET_LOWERLIMIT_F1
Description: Assigns the upper limit to switching output 2 and the lower limit to switching output 1.
Standard setting:
Switching output 1
Upper limit,
Switching output 2
Lower limit
