Serial Interface RS422
optoNCDT 1700
8.5.4 Set Average Number
Name: SET_AV0
Description: Sets the averaging number to 1 for moving and recursive averages, and to 3 for median.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x70 0x00 0x02 0x20700002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x70 0x00 0x02 0xA0700002
0x20 0x20 0x0D 0x0A 0x20200D0A
Name: SET_AV1
Description: Sets the averaging number to 4 for moving and recursive averages, and to 5 for median.
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x71 0x00 0x02 0x207130002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x71 0x00 0x02 0xA0710002
0x20 0x20 0x0D 0x0A 0x20200D0A
IMPORTANT!
The “avg“ LED shows
the current status
after the command
SET_AVO...3 on.
