Serial Interface RS422
optoNCDT 1700
8.5.21 Mastering or Setting Mid-point
Name: Set_Zero
Description: The command “SetşZero“ enables to
- set the sensor to mid-point in the operation mode “Error-Mode“ or
- mastering the sensor in the operation mode “Switch-Mode“
For sensors with software versions prior to 6,000 mid-point setting and mastering is possible with the sensor
button “select/zero“ or the digital “Zero“ input.
Parameter X:
0 = Undo set mid-point or mastering 1 = Set mid-point or mastering
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0D 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494c4431
0x20 0x66 0x00 0x03 0x20660003
0x00 0x00 0x00 0x0X 0x0000000X
Reply,
no error:
31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x66 0x00 0x02 0xA0660002
0x20 0x20 0x0D 0x0A 0x20200D0A
Reply,
with er-
ror:
31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xE0 0x66 0x00 0x03 0xA0660002
0x00 0x00 0x00 0x0X 0x0000000X
0x20 0x20 0x0D 0x0A 0x20200D0A
Error code X: Detailed information, see Chap. 8.4.2.
