Page 22
Installation
optoNCDT 1700
5.1 Sensor Mounting Diffuse Reflection
The sensor is mounted by means of 3 screws according to the table, see Fig. 6.
The bearing surfaces surrounding the fastening holes (through-holes) are slightly raised.
The laser beam must be directed perpendicularly onto the surface of the target after sensor mounting. In
case of misalignment it is possible that the measurement results will not always be accurate.
IMPORTANT!
Handle optical
sensors with care.
IMPORTANT!
Mount the sensor only
to the existing holes on
a flat surface. Clamps
of any kind are not per-
mitted. Do not exceed
torques.
