5. Installation
The sensor optoNCDT 1700 is an optical sensor for measurements with micrometer accuracy. Make sure it is handled carefully when
installing and operating.
Bolt connection Direct fastening
Housing Through
length
Screw Washer Tightening
torque per
screw
Screw depth Screw Tightening
torque per
screw
ISO 4762-A2 ISO 7089-A2 µ = 0.12 Minimum Maximum ISO 4762-A2 µ = 0.12
mm Nm mm mm Nm
S 30 M4 A4,3 2 - - - -
M 35 M4 A4,3 2 8 10 M5 3.5
L 48 M5 A5,3 3.5 9.6 10 M6 5
Fig. 6 Mounting conditions
Housing sizes, see Chap. 3.4.
Recommended tightening torque max. + 10 % permissible, not deceed min. -20 %!
The tightening torques specified in the table are approximate and may vary depending on the application.
Basis of considerations µ = 0.12
The bearing surfaces surrounding the fastening holes (through-holes) are slightly raised.
i
Mount the sensor only to the existing holes on a flat surface. Clamps of any kind are not permitted.
To align the sensor, please comply with the “Instructions for Operation“, see Chap. 9.3, especially.
If the sensors are to be used in soiled environments or in higher ambient temperatures than normal, MICRO-EPSILON recommends
the use of protective housings, see Chap. 9.4.
The suggested free space in the tuning range, see Fig. 8, is kept clear at least until the end of the measuring range of foreign material
and ambient light of other laser sensors.
