MICRO-EPSILON ILD1700-2 - A 3 Output Rate Optoncdt1700

Page 106
Appendix| Output Rate optoNCDT1700
optoNCDT 1700
A 3 Output Rate optoNCDT1700
Baud rate 115200 57600 19200 9600
Measurement
frequency
LED speed Bytes Synchron mode: Master on, Slave synchronized, Master off
2.5 kHz 1 2 2500 2500 833.33 416.66
Binary output
1.25 kHz 1/2 2 1250 1250 625 416.66
625 Hz 1/4 2 625 625 625 312.5
312.5 Hz 1/8 2 312.5 312.5 312.5 312.5
2.5 kHz 1 6 1250 833.33 277.77 138.88
ASCII output
1.25 kHz 1/2 6 1250 625 250 138.88
625 Hz 1/4 6 625 625 208.33 125
312.5 Hz 1/8 6 312.5 312.5 156.25 104.16
Synchron mode: Master alternating, Slave synchronized
(alternating)
2.5 kHz 1 2 1250 1250 625 416.66
Binary output
1.25 kHz 1/2 2 625 625 625 312.5
625 Hz 1/4 2 312.5 312.5 312.5 312.5
312.5 Hz 1/8 2 156.25 156.25 156.25 156.25
2.5 kHz 1 6 1250 625 250 138.88
ASCII output
1.25 kHz 1/2 6 625 625 208.33 125
625 Hz 1/4 6 312.5 312.5 156.25 104.16
312.5 Hz 1/8 6 156.25 156.25 156.25 78.12
