Page 66
Serial Interface RS422
optoNCDT 1700
Error output (Analog output)
0x20810003 SET_ERRORHANDLER
In case of error: Keep / do not keep last valid measurement
value
Synchron or trigger mode
0x20820003
SET_SYNCMODE
SET_TRIGGERMODE
Master / Slave, on, off, alternating;
triggering
Switching off the laser (external)
0x20870002 LASER_ON Switches the laser on
0x20860002 LASER_OFF Switches the laser off
Measurement value data format
0x20880003 ASCII_OUTPUT Options: ASCII / Binary
Key lock
0x20600003 SET_KEYLOCK Options: Keys enables or locked
Reset
0x20F10002 SET_DEFAULT Reset to default factory settings
0x20F00002 RESET_BOOT Reboot the sensor
Lock Flashwrite
0x20610003 WriteFlashZero Lock the Flashwriting for setting masters and the mid-point
Setting Masters, Setting Mid-Point
0x20660003 SET_ZERO
Start setting masters measurement respectively relative
measurement
