Laser class
optoNCDT 1700
The laser warning labels for Germany have already been applied. Those for other non German-speaking
countries an IEC standard label is included in delivery. The versions applicable to the user’s country must be
applied before the equipment is used for the first time. Laser operation is indicated by LED, see Chap. 3.5.
Although the laser output is low looking directly into the laser beam must be avoided. Due to the visible light
beam eye protection is ensured by the natural blink reflex.
The housing of the optical sensors optoNCDT 1700 may only be opened by the manufacturer, see Chap. 12.
For repair and service purposes the sensors must always be sent to the manufacturer.
laser off
error
o.k.
midrange
normal
zero
4 - 20 mA
0 - 10 V
RS 422
1
1/2
1/4
1/8
1
4
32
128
LASER RADIATION
Do not stare into the beam
CLASS 2 LASER PRODUCT
IEC 60825-1: 2014
optoNCDT
Laser spot
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
True reproduction of the sensor with its actual location of the warning labels, ILD1710-1000
