Page 45
Operation
optoNCDT 1700
Example:
Measurement range 50 mm, voltage output 0 ... 10 V
Mid-point is set at the position x
m
= 10 mm
Set mid-point results in an output signal of 5 V.
Remaining measurement range respectively
output range:
x
max
= 35 mm
Out
min
= 3 V respectively 8.8 mA
After setting mid-point the sensor gives new
measurement values, related to the mid-point.
The condition before setting mid-point can be
achieved by a reset.
Set mid-point (only error mode): no limit control
The displacement of the characteristic curve re-
duces the usable measurement range of the sensor.
0 V
5 V
10 V
100 %
x m
0 % Measurement range
4 mA
12 mA
20 mA
Output characteristic after setting
mid-point
Output characteristic
Out
min
x
max
161
8184
16207
Fig. 25 Characteristic for setting the mid-point
