4.0 WebUI Configuration
Protocol Config (continued)
In a Point-to-Multipoint
(PMP) network topology
which is to utilize UDP
multicast, typically the
MASTER would be
configured as ’(P)’ (the
POINT) and the
REMOTES would be
configured as ’(MP)’ (the
MULTIPOINTS).
 Multicast IP Address
A valid MULTICAST address that this unit will use to receive multicast UDP packets sent
by a UDP Point-to-Multipoint (P) unit. Note that the default value for this field matches
the default Multicast IP Address of the UDP Point-to-Multipoint (P) configuration
described on the previous page.
Default: 224.1.1.1
 Multicast Port
The UDP port that this unit will use, along with the Multicast IP Address detailed above,
to receive the multicast UDP packets sent by the UDP Point-to-Multipoint (P) unit.
Default: 20001
UDP Multipoint-to-Multipoint
 Multicast IP Address
A valid multicast address the unit will use to send multicast UDP packets upon receiving them
at its serial port.
Default: 224.1.1.1
 Multicast Port
UDP port that the packets are sent to. Multipoint stations should be configured to listen to
this port in order to receive multicast packets.
Default: 20011
 Time to Live
Time to live for the multicast packets.
Default: 1 (hop)
 Listening Multicast IP Address
A valid multicast address the unit is to listen to receive multicast UDP packets sent by
another UDP Multipoint-to-Multipoint unit.
Default: 224.1.1.1
 Listening Multicast Port
UDP port that the unit will listen to for multicast UDP packets sent by another UDP Multipoint-
to-Multipoint unit.
Default: 20011
