4.0 WebUI Configuration
Remote Setup > Subnet IP Address
Define the remote network by specifying the subnet local to that router.
Values (IP Address)
(no default)
Remote Setup > Subnet Mask
Specify the subnet mask of the remote network address.
Values (IP Address)
(no default)
IPsec Setup > Phase 1 DH Group
Select value to match the values required by the remote VPN router.
Values (selection)
modp1024/modp1536/
modp2048
Remote Setup > Certificate
If X.509 CA Authentication is selected, this field will appear. Enter the
certificate to be used by the current tunnel.
Values (characters)
(no default)
IPsec Setup > Mode
Select the IPsec IKE (Internet Key Exchange) mode used for
authentication. Main mode is the standard mode, but aggressive mode can
be used to provide faster negotiation.
Values (selection)
Main / Aggressive
Phase 1 Encryption
Select value to match the Phase 1 Encryption type used by the remote
VPN router.
Values (selection)
3des/aes/aes128/aes256
Phase 1 Authentication
Select value to match the Phase 1 Authentication used by the remote VPN
router.
Values (selection)
md5 / sha1
Phase 1 SA Life Time
Select value to match the values required by the remote VPN router.
Values
28800
