116 Using the RFID Functions
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3
3. Use the following panel function to enter the distance value (measured
transponder position value).
Select the menu item [Tag Position ] of the printer’s RFID menu.
The distance value is the first approximate value on the way to
adjust the optimal tag position.
OFFL
.
MENU
NEXT
ENTER
NEXT
ENTER
NEXT
ENTER
N
E
XT
ENTER
ESC ENTER
ENTER
Panel display
[ON LINE ]
[OFF LINE ]
[Menu Level 1 ]
& & &
[Engine ]
[Printspeed ]
& & &
[RFID Menu ]
[RFID Mode ]
& & &
[Tag Position ]
[Position: + 20 mm ]
& & &
[Position: + 48 mm ]
[Save as Setup? ]
Notes
Turn the printer OFF LINE with this key.
The MENU key gives the user access to the
menu structure.
Press the NEXT or PREVIOUS key until [Engine
] is displayed.
Press the NEXT or PREVIOUS key until
[RFID Menu ] is displayed.
Press the NEXT or PREVIOUS key until
[Tag Position ] is displayed.
The currently set value is displayed.
Press the NEXT or PREVIOUS key until the right
position value is displayed (in accordance with
the RFID labels in use; in this example a
distance of 48 mm was measured before).
The new tag position is saved
In addition this new value can be saved as
setup value (using the ENTER key).
After this decision turn the printer ON LINE
again: Press the ENTER key longer than 2
seconds.
