7.32. Adjusting the Tear Off Position (Option: Cutting Position)
The tear off position# is identical to the detected gap position, i.e. with the
perforation or the start of the label. With this function a fine setting of the tear off
position is carried out. The setting range for the offset is approximately ± 10 mm.
OFFL
.
MENU
NEXT
ENTER
NEXT
ENTER
NEXT
ENTER
N
E
XT
ENTER
ESC ENTER
ENTER
Panel display
[ON LINE ]
[OFF LINE ]
[Menu Level 1 ]
& & &
[Engine ]
[Printspeed ]
& & &
[TearOff Menu ]
[TearOff Mode ]
& & &
[TearOff Position ]
[Position: + 0.0 mm ]
& & &
[Position: - 0.5 mm ]
[Save as Setup? ]
Notes
Turn the printer OFF LINE with this
key.
The MENU key gives the user access
to the menu structure.
Press the NEXT or PREVIOUS key until
[Engine ] is displayed.
Press the NEXT or PREVIOUS key
until [TearOff Menu ] is displayed.
Press the NEXT or PREVIOUS key
until [TearOff Position ] is displayed.
The currently set value is displayed.
Press the NEXT or PREVIOUS key until
the desired offset is displayed.
The tear off position is shifted 0.5 mm
in feed direction.
In addition this new value can be
saved as setup value (using the ENTER
key).
After this decision turn the printer ON
LINE again: Press the ENTER key
longer than 2 seconds.
# If a cutter is installed and activated, the concerning panel function Cutting Position has to be used.
