7.33. Configuration of Network Parameters (IP Address, e.g.)
The functions of the submenu Network are used to set the
parameters for connecting the printer to a network (Ethernet).
Setting the IP address manually:
OFFL.
MENU
NEXT
ENTER
NEXT
ENTER
NEXT
ENTER
ENTER
NEXT
ENTER
ENTER
Panel display
[ON LINE ]
[OFF LINE ]
[Menu Level 1 ]
& & &
[Network ]
[Timeout ]
[IP Assign ]
[Off ]
& & &
[Manual ]
[IP Address ]
[192.168.002.002 ]
& & &
[192.168.010.123 ]
[Saved ! ]
Notes
Turn the printer OFF LINE with this key.
The MENU key gives the user access to the
menu structure.
Press the NEXT or PREVIOUS key until
[Network ] is displayed.
Press the ENTER key to select the Network
menu.
Press the NEXT or PREVIOUS key until
[IP Assign ] is displayed.
Press the ENTER key to select the IP Assign
menu.
The currently set configuration is displayed.
Press the NEXT or PREVIOUS key until
[Manual ] is displayed.
Press the ENTER key to set the IP address
manually.
Pushing the VAL+ or VAL- key changes the
value of the current position (left digit first,
in this example: 1). Pressing the NEXT key
moves you to the next digit (the PREVIOUS
key combination moves you back, if need
be).
The new IP address is saved as setup value.
Turn the printer ON LINE again:
Press the ENTER key longer than
2 seconds.
