Microplex LOGIJET T4 - Printhead Exchange

Operator Maintenance 143
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual LOGIJET T4 /T6 /RFID Edition 1.3
9.2. Printhead Exchange
!
Only use consumables being specially developed for this device.
Using unsuitable consumables or excessive contact pressure can
result in premature wearing of the printhead.
Only a MICROPLEX - trained operator is allowed to exchange the
printhead.
The following operations have to be done to carry out the
printhead exchange:
- Printhead removal and installation
- Adjusting the right printhead pressure
(see section 5.4 and section 9.3)
The printhead is adjusted to the printhead mounting during
manufacture. Therefore the printhead can only be replaced in
conjunction with the printhead mounting.
Fig. 9.2.a Printhead with printhead mounting
Printhead
mounting
Printhead
