Microtest OMNIScanner2 User Manual

A - 3
OMNIScanner User Guide
Universal Serial Bus
• Type Self Powered Device
• Link 12 MB/s Full Speed Bulk Transfer with
two 128 byte FIFOs and Automatic Retry
• Connector Type ‘B’ Receptacle
• Recommended Cable Full Speed Shielded Twisted Pair with A-B
Plugs (USB V1.1 Complaint)
MultiMediaCard Interface
• Link 4.6 MB/s SPI Mode with 16 bit CRC
• Format 512 byte sector size, 32Bit FAT File
System
• Socket Non-Locking Seven Contact with Ejector
• Recommended Media Sandisk SDMB-xx or Infineon
MultiMediaCard-F00xx (xx denotes
memory size in Megabytes)
Memory
• Control: Flash Memory allows electronic upgrading of both OMNI-
Scanner and OMNI Remote programs.
• Test Storage: Up to 1000 complete Autotest results can be stored in
permanent flash memory. They are not subject to loss due to power or
battery failures.
OMNI Scanner Autotest Functions
• Full suite of tests to determine if cable meets generic cabling or network
type requirements.
• Extended performance range Cabling (CAT 6 and CAT 7)
• TIA standard Autotests
• ISO/IEC standard Autotests
• Vendor specific Autotests
• IEEE standard Autotests
• ATM standard Autotests
• FDDI standard Autotests
• AS/NZ standard Autotests
• ANSI standard Autotests
OMNI Scanner Test Functions
• Wire Map
• NEXT (Near End Crosstalk)
• Return Loss
