4-7. Naming Convention For Miller Welding Assignments − GMAW/FCAW
MATERIAL THICKNESS
Inch Fraction
JOINT TYPE
T=T-Joint
L=Lap Joint
B=Butt Joint
WELD POSITION
1F/1G=Flat
2F/2G=Horizontal
3F/3G=Vertical
4F/4G=Overhead
WELDING PROGRESSION
P=Push
D=Drag
Up=Uphill
Dwn=Downhill
WELDING PROCESS
GMAW=GMAW
GMAWS=GMAW-S
GMAWP=GMAW-P
FCAWG=FCAW-G
NUMBER OF PASSES
Integer
1/8 -1-GMAWS(P)-2FT
4-8. Naming Convention For Miller Welding Assignments − SMAW
MATERIAL THICKNESS
Inch Fraction
JOINT TYPE
T=T-Joint
Lap=Lap Joint
Butt=Butt Joint
WELD POSITION
1F/1G=Flat
2F/2G=Horizontal
3F/3G=Vertical
4F/4G=Overhead
WELDING PROGRESSION
P=Push
D=Drag
Up=Uphill
Dwn=Downhill
ELECTRODE TYPE
NUMBER OF PASSES
Integer
1/8 -1-E6010(D)-2FT
