7-2B. Select Assignment
1. Select desired assignment (Figure 7-4). Note the corresponding weld process, joint type, and position (flat or horizontal). View more assignments
by touching link at bottom of screen. Screen also displays history of previous tests. Select Filters to narrow your search for specific assignments.
Corresponding
SmartGun Display
Select Filters to help locate
specific assignment(s).
Screens shown are representative. Specific options may vary with weld process.
Figure 7-4. Welding Assignment Screen
