OM-267357 Page 56
13-2. Emptying Work Table Particle Tray
! Before each use, check tray and
empty the particles into a fire-
proof container.
! Do not operate unit without parti-
cle tray.
1 Hand Knobs
After emptying particle tray, reinstall
and tighten hand knobs.
Ref. 268609-D
Tools Needed:
1
13-3. Overload Protection
! Turn off power and disconnect
input power cord.
1 Fuses F1, F2
(See Parts List For Rating)
F1 and F2 protect the internal computer
and power supply from overload. If ei-
ther of these fuses open the unit does
not operate. Check fuse(s) and replace
if open.
To access fuses, use a screwdriver to
remove the power receptacle cover
plate.
If a fuse opens, it usually indicates
a more serious problem exists.
Contact a Factory Authorized Ser-
vice Agent.
Tools Needed:
Ref. 268609-D / 161-051
1
