OM-267357 Page 64
Description
Part
No.
Dia.
Mkgs.
Item
No.
Figure 16-1. Weld Table And Monitor Assembly (Continued)
Quantity
20 277826 Kit, LiveArc SmartGun Replacement (See Figure 16-2) 1... .......... .. ..................
21 277824 Kit, LiveArc SmartStinger Replacement 1... .......... .. ...............................
*♦275910 Cable Assy, 15 Ft Dinse Male To Female 50 Series 1.............. .. ......................
22 266675 Cover, Speaker 1... .......... .. .....................................................
23 +268933 Arm, Extension 1... ......... .. .....................................................
24 267430 Label, Caution Moving Parts 2... .......... .. ..........................................
25 271184 Knob, T 2.000 Bar W/.375 Stud 1.5 Barrel 1... ........... .. ..............................
26 271183 Knob, T 3.000 Bar W/.312-18 Stud 1.000 Lg 1... ........... .. ............................
27 266700 Table Top, LiveArc Reversible Panel 1... .......... .. ...................................
28 275363 Assembly, Cal Tool And Dust Tray 1... .......... .. .....................................
29 244965 Foot, Mtg Arcstation 4... .......... .. .................................................
30 278115 Tool, Weld Joint Calibration 1... ........... .. ...........................................
31 +♦275484 Assembly, Router Box (Includes) 1... ........ .. ......................................
267504 Power Cord, LiveArc No 16/3 15 ft 1................ .... ...................................
32 ♦272813 Label, Warning High Voltage 1... ......... .. ..........................................
33 ♦275795 Cable Assy, Livearc To Router Box Communication 1... ......... .. ......................
34 ♦274827 Tool, Livearc Stinger Calibration 1... ......... .. .......................................
35 ♦267571 Tool, Livearc Smartgun Calibration 1... ......... .. ....................................
36 ♦271475 Tool, Livearc Table Calibration 1... ......... .. ........................................
37 ♦270711 Block, Calibration Out Of Position 1... ......... .. .....................................
38 ♦270959 Indicator, Level 2 Way Magnetic (WTS) 1... ......... .. ................................
* Recommended Spare Parts.
♦OPTIONAL
+ When ordering a component originally displaying a precautionary label, the label should also be ordered.
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and serial number required when ordering parts from your local distributor.
