3-1
3 Installation Guide
3.1 Preparations
3.1.1 Accessories
The following additional materials are required before installation. The customer is responsible
for supplying these materials. Missing items may result in delays, incomplete installation, and/or
additional service visits.
Compatible emergency O2, N2O, and air cylinders
Anesthetic vaporizers (if not purchased with the anesthesia system) and adapters
Active O2, N2O, and air supplies (280–600 kPa (40–87 psi)) and connectors adapting to the
hospitals' gas supplies Double-gauge pressure relief valve if the gas supply pressure is
greater than 600 kPa (87 psi)
Negative pressure source and negative pressure source connection hoses (if not purchased
with the anesthesia system)
Vaporizers are required to be purchased from Mindray for the A9. The Mindray
electronic vaporizers need to be tested with the A9 during installation.
3.1.2 Tools
Phillips screwdriver
Scissors
3.2 Installation Procedure
This section describes other applicable basic information. Use the anesthesia
machine with calibrated flow sensors. If the calibrated flow sensors are removed,
ensure that they are reinstalled on the original anesthesia machine. If different flow
sensors are reinstalled, recalibrate them.
When unpacking the machine, keep as much of the plastic covering on the machine
as possible. When all parts are unpacked, return the packing material to its
original box. Place the smaller box inside the larger box.
