Mindray A8 Service Manual

8-72
10. Pull out the caster driven shaft (0645) for a certain distance, remove the four screws from
the STEINCO 5-inch central control caster with the M6 hexagon screw spanner, and pull out
the caster upward.
8.78 Disassemble the STEINCO 5-Inch Standalone Brake
Casters
8.78.1 Prepare for Disassembly
8.78.1.1 Tools
During parts disassembly and replacement, the following tools may be required:
 Phillips screwdriver
 M6 hexagon screw spanner
8.78.1.2 Preparations
Before disassembly,
 Make sure that the anesthesia machine is turned off and disconnected from the A/C power
source.
 Bleed down the gas pressure inside the anesthesia machine as instructed.
 Disconnect all pipeline and cylinder gas supplies.
 Maneuver the anesthesia machine to an appropriate location and then apply the brake.
Caster driven shaft (0645)
