Mindray A8 Service Manual

8-73
8.78.1.3 Pre-disassembly
Refer to steps 1 to 5 in 8.76.2Remove the STEINCO 5-Inch Central Control Caster to remove
the chassis.
8.78.2 Remove the STEINCO 5-Inch Standalone Brake Casters
1. Turn over the chassis and remove the six screws with the Phillips screwdriver to remove the
rear housing of the chassis.
2. Remove the four screws from each of the left and right casters with the M6 hexagon screw
spanner and remove the two STEINCO 5-inch standalone brake casters.
Rear housing of the chassis
STEINCO 5-inch
standalone brake caster
