Mindray A8 - Remove the Upper-Left Cover Plate

8-11
3. Disconnect the cables and tubes from the instrument panel assembly and remove the
assembly.
Figure A
Figure B
8.13.6 Remove the Upper-Left Cover Plate
1. Remove APL valve.
2. Remove the vacuum regulator - 2 screws to remove the cover and 4 screws from the inside.
3. Disconnect tubes 147 and 148b.
3. Remove the five screws from the upper-left cover plate with the Phillips screwdriver.
2. Disconnect the cables and tubes from the upper-left cover plate assembly of the work
surface and remove the assembly.
BFCS door
Instrument panel assembly
