Mindray A8 - Remove the VE Mounting Box In-Position Switch; Pre-Disassembly (Disassemble Housings and some System Parts); Open the Service Door; Remove the Auxiliary Output Assembly

8-9
8.12.2 Remove the VE Mounting Box In-Position Switch
Remove the two screws with the Phillips screwdriver, remove the protection cap, disconnect the
plug, and then pull out the in-position switch.
8.13 Pre-disassembly (Disassemble Housings and Some System
Parts)
8.13.1 Open the Service Door
Remove the five screws from the service door with the Phillips screwdriver to open the door.
8.13.2 Remove the Auxiliary Output Assembly
Remove the six screws from the auxiliary output assembly with the Phillips screwdriver to
remove the assembly and disconnect 4 cables.
Auxiliary output
assembly
Service door
In-position switch
