3-5
10. Create a ramp by placing the top plate in front of the pallet and gently push the A8/A9
down the ramp.
3.2.2 Installation
1. Check the accessories according to the packing list.
2. Take the bag arm assembly out of the bottom drawer. Remove the bubbled wrap from the
bag arm assembly and bag arm mounting base with a pair of scissors.
3. Carefully put the bag arm assembly in the groove and tighten the nut clockwise to install the
bag arm assembly on the breathing circuit.
