11.1.4 High-Flow O2 Supply Assembly, Anesthesia Calculation Inlet

Pipeline Assembly, and EFCS Flowmeter Service Part

No. Name P/N Test Item After

Replacement

Remarks

High-Flow O2 Supply

Assembly

115-077955-00

5.9.1 High-flow O2

supply test

Power on the

A8/A9 and

switch the

HFNC on

after the

maintenance.

Anesthesia calculation

inlet pipeline assembly

(A9)

115-065016-00

5.9.5 Internal AG module

test; 5.7.1Vaporizer

Monitoring Function Test

EFCS flowmeter FRU

(O2/N2O/Air)

115-077959-00

5.5 EFCS accuracy test

5.6 BFCS function test
