Mindray A8 - Remove the STEINCO 5-Inch Central Control Caster

8-69
8.77.1.2 Preparations
Before disassembly,
 Make sure that the anesthesia machine is turned off and disconnected from the A/C power
source.
 Maneuver the anesthesia machine to an appropriate location and then apply the brake.
8.77.2 Remove the STEINCO 5-Inch Central Control Caster
1. Refer to 8.1.1Open the Service Door to open the service door.
2. Refer to 8.36Disassemble the Battery Box Assembly to remove the battery box assembly.
3. Remove the four screws from the left and right rails at the bottom with the Phillips
screwdriver to remove the rails.
4. Remove the six screws on the left and right fixed cart rails and the two screws on the left
and right of the service door with the hexagon screw spanner, and lift the upper half to
remove it.
5. Remove the four screws on each of the left and right side panels with the Phillips
screwdriver to remove the side panels.
