11.1.15 VE Mounting Box Assembly

No. Name P/N Test Item After

Replacement

Remarks

SWITCH, small-stroke,

caster-type, 200 gf

M07-00010S-00

5.7.1 Vaporizer

Monitoring

Function Test

VE mounting box

in-position switch
