11.1.10 Circuit Adapter Block Assembly

No. Name P/N Test Item After

Replacement

Remarks

Circuit adapter block assembly

(circuit connector adapter

assembly)

115-066856-00

5.2 System Check;

5.7.1 Vaporizer

Monitoring Function

Test

Auto/manual position detection

switch

009-008835-00

5.10.2 APL Valve Test;

5.7.1 Vaporizer

Monitoring Function

Test

Cables are

included.
